LOAD CELL TYPE S ZEMIC H3F

Update Terakhir
:
26 / 11 / 2018
Min. Pembelian
:
1 Unit
CV. JATIM TRONIK merupakan perusahaan SUPPLIER TIMBANGAN dan PERLENGKAPANNYA. Kami juga melayani Jasa Service, Instalasi, Modifikasi, Jasa Tera dan Kalibrasi, serta Fabrikasi Konstruksi Timbangan di Seluruh Indonesia.

AVERY–AND–MK CELLS–CAS–DIGI–KUBOTA–GSC–ZEMIC–SONIC–PRECISA–DINI ARGEO– PT–KELI–METTLER TOLEDO–SAYAKI–RINSTRUM–EXCELLENT–FLINTEC

Detail LOAD CELL TYPE S ZEMIC H3F

Zemic H3F

Zemic H3F load cell are available in the capacities 25kg to 30t and 100lb to 20klb. Alloy steel, sealed by adhesive inside, oil-proof, waterproof and anti-corrosion, suitable for all kinds of environments. S beam design, tension and/or compression loading possible, easy installation, suitable for crane scale, mechanical conversion scale, hopper scale and other electronic weighing devices. Safe and anti-explosive product, can be used in atrocious environment and hazardous areas.

NTEP: Certificate no. 06-099A1





SPECIFICATIONS : ZEMIC H3F LOAD CELL

Capacity t 0.1 / 0.25 / 0.5 / 0.75 / 1 / 1.5 / 2 / 2.5 / 5
lb 250 / 500 / 750 / 1K / 1.5K / 2K / 2.5K / 3K / 5K / 7.5K / 10K / 15K / 20K
Accuracy   C2 C3 A5S A5M B10S B10M
Maximum number of  verification intervals n max 2000 3000 5000 5000 10000 10000
Minimum load cell verification interval v min Emax
/5000
Emax
/10000
Emax
/15000
Emax
/15000
Emax
/10000
Emax
/10000
Combined error %FS ≤ ±0.030 ≤ ±0.020 ≤ ±0.018 ≤ ±0.026 ≤ ±0.035 ≤ ±0.050
Creep %FS/30min ≤ ±0.024 ≤ ±0.016 ≤ ±0.012 ≤ ±0.017 ≤ ±0.030 ≤ ±0.040
Temperature effect on sensitivity %FS/10℃ ≤ ±0.017 ≤ ±0.011 ≤ ±0.009 ≤ ±0.013 ≤ ±0.030 ≤ ±0.040
Temperature effect on zero %FS/10℃ ≤ ±0.023 ≤ ±0.015 ≤ ±0.010 ≤ ±0.014 ≤ ±0.030 ≤ ±0.020
Output sensitivity mv/v 3.0 ± 0.008
Input resistance Ω 350 ± 3.5
Output resistance Ω 351 ± 2
Insulation resistance ≥ 5000 (50V DC)
Zero balance %FS 1.0
Temperature, compensated -10 ~ +40
Temperature, operating -35 ~ +65
Excitation, recommended V 5 ~ 12 (DC)
Excitation, max V 18 (DC)
Safe overload %FS 150
Ultimate overload %FS 300
Tampilkan Lebih Banyak
